Fashion-MNIST Project

Table of Contents

In this project, you will classify Fashion-MNIST dataset using convolutional neural networks.

Estimated Time Needed: 30 min

Preparation

Download the datasets you needed for this lab.

The following are the PyTorch modules you are going to need

python
# !pip install torch
# !pip install torchvision
# !pip install matplotlib
python
# PyTorch Modules you need for this lab

from torch.utils.data import Dataset, DataLoader

from torchvision import transforms
import torch
import torch.nn as nn
import torchvision.transforms as transforms
import torchvision.datasets as datasets
torch.manual_seed(0)

Import Non-PyTorch Modules

python
# Other non-PyTorch Modules

from matplotlib.pyplot import imshow
import matplotlib.pylab as plt

from PIL import Image
python
def show_data(data_sample):
    plt.imshow(data_sample[0].numpy().reshape(IMAGE_SIZE, IMAGE_SIZE), cmap='gray')
    plt.title('y = '+ str(data_sample[1]))

Questions 1: Create a Dataset Class

In this section, you will load a Dataset object, but first you must transform the dataset. Use the Compose function to perform the following transforms:.

  1. Use the transforms object to Resize to resize the image.
  2. Use the transforms object to ToTensor to convert the image to a tensor.

You will then take a screen shot of your validation data.

Use the Compose function to compose the transforms

python
#Hint:

IMAGE_SIZE = 16

transforms.Resize((IMAGE_SIZE, IMAGE_SIZE)),
transforms.ToTensor()#
composed = transforms.Compose([transforms.Resize((IMAGE_SIZE, IMAGE_SIZE)), transforms.ToTensor()])

Create two dataset objects for the Fashion MNIST dataset. One for training data called dataset_train and one for validation data dataset_val. You will be asked to take a screenshot of several samples.

Hint: dsets.FashionMNIST(root= '.fashion/data', train=???, transform=composed, download=True)

python
# Enter your code here
dataset_train = datasets.FashionMNIST(root = './data', train = True, download = True, transform = composed)
dataset_val = datasets.FashionMNIST(root = './data', train = False, download = True, transform = composed)
python
for n,data_sample in enumerate(dataset_val):

    show_data(data_sample)
    plt.show()
    if n==2:
        break

Questions 2

Create a Convolutional Neural Network class using ONE of the following constructors. Train the network using the provided code then provide a screenshot of your training cost and accuracy with your validation data.

Constructor using Batch Norm

python
class CNN_batch(nn.Module):

    # Constructor
    def __init__(self, out_1=16, out_2=32,number_of_classes=10):
        super(CNN_batch, self).__init__()

        # Layer stack 1
        self.cnn1 = nn.Conv2d(in_channels=1, out_channels=out_1, kernel_size=5, padding=2)
        self.conv1_bn = nn.BatchNorm2d(out_1)
        self.maxpool1=nn.MaxPool2d(kernel_size=2)

        # Layer stack 2
        self.cnn2 = nn.Conv2d(in_channels=out_1, out_channels=out_2, kernel_size=5, stride=1, padding=2)
        self.conv2_bn = nn.BatchNorm2d(out_2)
        self.maxpool2=nn.MaxPool2d(kernel_size=2)

        # Fully connected - Final layer
        self.fc1 = nn.Linear(out_2 * 4 * 4, number_of_classes)
        self.bn_fc1 = nn.BatchNorm1d(10)

    # Prediction
    def forward(self, x):
        x = self.cnn1(x)
        x=self.conv1_bn(x)
        x = torch.relu(x)
        x = self.maxpool1(x)
        x = self.cnn2(x)
        x=self.conv2_bn(x)
        x = torch.relu(x)
        x = self.maxpool2(x)
        x = x.view(x.size(0), -1)
        x = self.fc1(x)
        x=self.bn_fc1(x)
        return x

Constructor for regular Convolutional Neural Network

python
class CNN(nn.Module):

    # Constructor
    def __init__(self, out_1=16, out_2=32,number_of_classes=10):
        super(CNN, self).__init__()

        # Stack 1
        self.cnn1 = nn.Conv2d(in_channels=1, out_channels=out_1, kernel_size=5, padding=2)
        self.maxpool1=nn.MaxPool2d(kernel_size=2)

        # Stack 2
        self.cnn2 = nn.Conv2d(in_channels=out_1, out_channels=out_2, kernel_size=5, stride=1, padding=2)
        self.maxpool2=nn.MaxPool2d(kernel_size=2)

        # Fully connected - Final layer
        self.fc1 = nn.Linear(out_2 * 4 * 4, number_of_classes)

    # Prediction
    def forward(self, x):
        x = self.cnn1(x)
        x = torch.relu(x)
        x = self.maxpool1(x)
        x = self.cnn2(x)
        x = torch.relu(x)
        x = self.maxpool2(x)
        x = x.view(x.size(0), -1)
        x = self.fc1(x)
        return x

train loader and validation loader

python
train_loader = torch.utils.data.DataLoader(dataset=dataset_train, batch_size=100 )
test_loader = torch.utils.data.DataLoader(dataset=dataset_val, batch_size=100 )

Convolutional Neural Network object

python
#model = CNN(out_1=16, out_2=32,number_of_classes=10)
model =CNN_batch(out_1=16, out_2=32,number_of_classes=10)

Create the objects for the criterion and the optimizer named criterion and optimizer. Make the optimizer use SGD with a learning rate of 0.1 and the optimizer use Cross Entropy Loss

python
# Enter your code here
criterion = nn.CrossEntropyLoss()

optimizer = torch.optim.SGD(model.parameters(), lr=0.1)

Code used to train the model

python
import time
start_time = time.time()

cost_list=[]
accuracy_list=[]
N_test=len(dataset_val)
n_epochs=5
for epoch in range(n_epochs):
    cost=0
    model.train()
    for x, y in train_loader:
        optimizer.zero_grad()
        z = model(x)
        loss = criterion(z, y)
        loss.backward()
        optimizer.step()
        cost+=loss.item()
    correct=0
    #perform a prediction on the validation  data
    model.eval()
    for x_test, y_test in test_loader:
        z = model(x_test)
        _, yhat = torch.max(z.data, 1)
        correct += (yhat == y_test).sum().item()
    accuracy = correct / N_test
    accuracy_list.append(accuracy)
    cost_list.append(cost)

You will use the following to plot the Cost and accuracy for each epoch for the training and testing data, respectively.

python
fig, ax1 = plt.subplots()
color = 'tab:red'
ax1.plot(cost_list, color=color)
ax1.set_xlabel('epoch', color=color)
ax1.set_ylabel('Cost', color=color)
ax1.tick_params(axis='y', color=color)

ax2 = ax1.twinx()
color = 'tab:blue'
ax2.set_ylabel('accuracy', color=color)
ax2.set_xlabel('epoch', color=color)
ax2.plot( accuracy_list, color=color)
ax2.tick_params(axis='y', color=color)
fig.tight_layout()

dataset: https://github.com/zalandoresearch/fashion-mnist

About the Authors:

Joseph Santarcangelo has a PhD in Electrical Engineering, his research focused on using machine learning, signal processing, and computer vision to determine how videos impact human cognition. Joseph has been working for IBM since he completed his PhD.

Other contributors: Michelle Carey, Mavis Zhou
